Abrasive type: Diamond

Backing material: Heavy cotton.

Grit sizes: Coarse < P60, 120, 200, 400 > Fine

Backing material: Heavy cotton

Application:

Spirals bands can be used on hard to grind materials such as glass, porcelain, rhodium, iridium, titanium, technical ceramics and hard coatings like tungsten carbide. Finishing of corners, edges and cleaning of hard to reach areas. The spiral bands remove uneven surfaces, ensure flatness providing an excellent base for fittings. They can be used for shaping, cleaning edges of drilled holes and corner dubbing. Artisan companies use them for shaping sculptures.

Specialised glass companies, like glass fencing firms (swimming pools) utilise KGS spiral belts for shaping and cleaning the edges of drilled holes (for locking systems) in glass doors. Spiral belts are also used for corner dubbing applications which need a high accuracy and fine adjustments. Available up to Ø150 mm for expanding rubber drums. These products are often used in the crystal glass industry, lapidary, technical quartz, and in the stone industry. Spiral bands are ideal for curved and contoured surfaces that need high attention and accuracy. Polishing of corners, edges and cleaning of hard to reach areas, like pre-moulded holes of porcelain sanitary ware.

Types of machine to use:

Hand-held machines. The spiral belts have a reinforced backing which allows high speeds up to 45 m/s ensuring a superb finish. Optimum speed will vary with the material ground. Slower speeds may prove beneficial with the finer grits.

For more information on this and other diamond coated abrasive products click here!

Delivery for this product is 3-4 weeks.
